Product Features:
1.Products are applied to heating metering, multi-mode heating balance regulation and control, remote control.
2.Consistent with conventional heat meters and directly replaceable.
3.Ultrasonic metering, no mechanical wear and tear, longer service life
4.Accuracy level:Class 2
5.Range ratio:R50/R100/125/160
6.Temperature range:(4~95)°C
7.Temperature range:(2~90)K
8.Conform to national standard:EN1434
9.Communication interface diversity:
Optical/MBUS/RS485/LoRaWan/NB-loT/Zigbee/wMBUS
10.Replaceable battery design
Various valve adjustment modes are available:
1.Set instantaneous flow regulation
2.Set instantaneous powerrequlation
3.Set return water temperature regulation
4.Set the average temperature of the inlet and return water regulation
5.Adjustment of the valve opening according to the acquired room temperature
6.System strength set open degree, forced open/close valve
Technical Parameter
|
Performance |
Parameter |
|||
|
Diameter |
Min.Flow |
Nominal Flow |
Max,Flow |
Length |
|
qmin(m³/h) |
qp(m³/h) |
qmax(m³/h) |
mm |
|
|
DN15 |
0.015 |
1.5 |
3 |
130 |
|
DN20 |
0.05 |
2.5 |
5 |
130 |
|
DN25 |
0.07 |
3.5 |
7 |
160 |
|
DN32 |
0.12 |
6 |
12 |
180 |
|
DN40 |
0.2 |
10 |
20 |
200 |
|
Accuracy |
Class 2 |
|||
|
Connection type |
Thread connection |
|||
|
Pressure Loss |
≤0.02MPa |
|||
|
Max. working pressure |
1.6MPa |
|||
|
Temperature sensor |
1.5m standard two-wire PT1000 paired temperature |
|||
|
Data Storage |
Continues storage of the pevious 24 months of history |
|||
|
Transmission |
Optical/MBUS/RS485/LoRaWan/NB-loT/Zigbee/wMBUS |
|||
|
Power |
3.6V Lithium battery/External DC24V |
|||
|
Protection Class |
IP65/IP67 |
|||
|
Environmental |
Class A |
|||
|
Temperature range |
(4~95)℃ |
|||
|
Temperature difference range |
(2~90)K |
|||
|
Installation Method |
Water inlet or water return (default water inlet, water return installation should be specified when ordering) |
|||
|
Installation |
Horizontal or Vertical |
|||
|
Battery life |
Use cycle ≥ 6 years |
|||
|
Display |
8-bit LCD liquid crystal display |
|||
|
Anti-magnetic interference |
When subjected to magnetic field interference with intensity not greater than 100KA/m, lt should not affect the metering and remote transmission characteristics of the heat meter |
|||
External Dimensions
| Nominal Diameter |
DN15 |
DN20 |
DN25 |
DN32 |
DN40 |
|
Thread |
G3/4B |
G1B |
G11/4B |
G11/2B |
G2B |
|
L(mm) |
130 |
130 |
160 |
180 |
200 |
|
W(mm) |
88 |
88 |
88 |
88 |
88 |
|
H(mm) |
125 |
129 |
136 |
139 |
149 |
|
Customised threads available |
|||||
